Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

زبون مراجعة
آلة سهلة الاستخدام. رئيسه هو لطيف جدا.

—— السيد أنجولون من أوروبا

هذه الشركة مصنعة جيدة ، ومتحدث جيد باللغة الإنجليزية ، وأنا أحب أجهزتك. انها ذات نوعية جيدة ، وجميلة!

—— Mr.Mark من افريقيا

مورد لطيف! أنا أحب التسليم السريع ودورة الإنتاج السريعة ، وسوف نبقى على اتصال مع اللاعبين.

—— السيد جاك من أمريكا

ابن دردش الآن

Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line
Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line
Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

صورة كبيرة :  Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

تفاصيل المنتج:
مكان المنشأ: Botou Hebei China
اسم العلامة التجارية: HC
إصدار الشهادات: ISO
رقم الموديل: HC25
شروط الدفع والشحن:
الحد الأدنى لكمية: 1set
الأسعار: 8000-29000USD
تفاصيل التغليف: Main machine is nude,the computer control box is packed by carton box
وقت التسليم: 30days
شروط الدفع: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
القدرة على العرض: 20 sets/month

Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

وصف
Material: G550 Thickness: 0.3-0.6mm
Speed: 8-10m/min
تسليط الضوء:

cold roll forming machine,roof panel roll forming machine

,

roof panel roll forming machine

Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line

Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line 0Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line 1Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line 2



Description: Automatic Roofing Roll Forming Machine Cold Rolled Steel Panel Forming Line



 Main parameter

No.

   Main parameter of Roofing Sheet Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

914mm

3

Rollers

19 rows

4

Dimensions

9100*1450*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)



7

Thickness of the plate

0.3-0.6mm

8

Productivity

15-20m/min

9

Diameter of the roller

Φ70mm

10

Voltage

380V 50Hz 3phases

11

Material of the cutting plate

Cr12

12

Hydraulic

40#

13

Processing precision

Within 1.00mm

14

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting





Application



This type of sheet can be widely used in plant, house, storage and simple steel roof and wall. It has advantage of pretty appearance, durable using and so on.



Our firm is engaged in offering a wide array of Corrugated Roof Roll Forming Machine that is widely used in construction industry for making the roof tile and wall panel outside of building. The components used for its fabrication are procured from reliable sources of the market to deliver high performance and superior quality at users end. Our offered Corrugated Roof Roll Forming Machine is highly appreciated for its outstanding functionality, sturdy construction, optimum strength, easy usage and longer functional life. We offer this machine in different specifications to fulfill the diverse needs of clients at most affordable prices.
