Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall

زبون مراجعة
آلة سهلة الاستخدام. رئيسه هو لطيف جدا.

—— السيد أنجولون من أوروبا

هذه الشركة مصنعة جيدة ، ومتحدث جيد باللغة الإنجليزية ، وأنا أحب أجهزتك. انها ذات نوعية جيدة ، وجميلة!

—— Mr.Mark من افريقيا

مورد لطيف! أنا أحب التسليم السريع ودورة الإنتاج السريعة ، وسوف نبقى على اتصال مع اللاعبين.

—— السيد جاك من أمريكا

ابن دردش الآن

Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall

Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall
Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall
Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall

صورة كبيرة :  Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall

تفاصيل المنتج:
مكان المنشأ: CN
اسم العلامة التجارية: HC
إصدار الشهادات: ISO CE
رقم الموديل: HC17-61-999
شروط الدفع والشحن:
الحد الأدنى لكمية: 1 set
الأسعار: USD10000-16000 per set
تفاصيل التغليف: Standard Export Package
وقت التسليم: 40 days
شروط الدفع: L/C, D/A, D/P, T/T, Western Union, MoneyGram
القدرة على العرض: 20 set per month

Custom IBR Roofing Sheet Roll Forming Machine 0 - 15m / min For Wall

وصف
Type: Metal roofing sheet roll forming machine Suitable market: Asia
Usage: Roof and wall Power: 4+4KW
Voltage: 380V or customized Worker: 1 only
Forming speed: 10-20m/min Life time: 20 years above
Warranty: Whole life
تسليط الضوء:

roof tile roll forming machine,cold roll forming machine

,

cold roll forming machine

IBR Roofing Sheet Roll Forming Machine



We are one of the leading organization occupied in providing Metal Roofing Sheet Roll Forming Machine, which are producing by using high grade material.we designed a lots kinds of Metal Roofing Sheet Roll Forming Machine. due to the high graded superiority and our client fulfillment,The product by Metal Roofing Sheet Roll Forming Machine has many benefit such as beautiful and colorful outside, light weigh, long life durability. It was widely used in every corn world wide. we can develop special Metal Roofing Sheet Roll Forming Machine as per customer requirement.



Quick Details IBR Roofing Sheet Roll Forming Machine

1. Suitable to process: Color steel plate
2. Width of the plate: 1219mm
3.  Rollers: 17 rows
4. Dimensions: 8.2.55*1.51m
5. Power: 4+4kw
6. Rolling material: high grade 45# steel(plated chrome on surface)
7. Thickness of the plate:0.3-0.6mm
8. Voltage: 380V 50Hz 3phases
9. Material of the cutting plate: Cr12

10. Hydraulic: 40#
11. Processing precision: Within 1.00mm
12. Control system: PLC control
Please note: All the parameters can be designed as customer's requirements.



Clear about working process for Roof Sheet Roll Forming Machine ?
Decoiling--Feeding & Guiding--Roll Forming--Cutting--Finished Products To Support Table

No.

   Main parameter of Roof Sheet Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1219mm

3

Rollers

17 rows

4

Dimensions

8200*1550*1510mm

5

Power

4+4kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Why choose Huachen ?


1. Q: Do you have after sales support?
A: Yes, we are happy to give advice on machine operating and maintenance. we also have skilled technicians available abroad to help you.We need your machines running in order to keep your business running.

2. Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly .We need to make gress to move forward.

3. Q: How does your factory do regarding quality control?
A: Quality is priority.To all Huachen people,the concept "Control every process and perfect all products" is curved in mind. Every product will be fully assembled and carefully tested before it's packed for shipment.

4. Q: Do you sell only standard machines?
A: No, most of our machines are designed according to customers specifications,we offer OEM service.

5. Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. welcome to come and check your machine after finished, or we will show you machine working video for confirm. Then delivery.
