تفاصيل المنتج:
|
| color: | blue | Warranty: | 1 Year |
|---|---|---|---|
| control system: | PLC control | cutting method: | hydraulic cut |
| working speed: | 8-10m/min | Control system: | PLC(imported Brand) |
| تسليط الضوء: | sheet metal roll forming machines,corrugated roll forming machine,corrugated roll forming machine |
||
| Item | Specification |
| Decoiler | 5 tons /10 tons /12 tons or as your request |
| Roller material | 45# steel , 0.05mm chrome coated / GCR15 |
| Shaft diameter | 75mm, 100% solid |
| Machine frame | 400H steel |
| Machine structure thickness | 20mm |
| Hydraulic cutting | Guide Pillar cutting style |
| PlC brand | Delta ,Siemens ,panasonic, |
| Touch screen computer | touchwin |
| Receiving table | 3meters * 2 sets |
| Chain transmission | 1" |
| Chain wheel | 1" |
| Voltage | 380V/50HZ/3phase or as your request |
| Computer box type | placed in ground or fixed on machine |
| Machine color | customzied |
Packaging
1. Tighten to container with steel wire rope and welded machine with container by angel iron
2. Main forming machine and un-coiler is naked(If you need we can also packed with water-proof plastic)
3. PLC contral system and motor pump are packed in wooden box with water proof paper coverage
