تفاصيل المنتج:
|
| إبراز: | sheet metal roll forming machines,corrugated roll forming machine,corrugated roll forming machine |
||
|---|---|---|---|
1:Product Description:
Double layer metal roof panel roll forming machine
Application:
Agricultural Warehouses l Garages l Sheds l Hygienic Greenhouses l Sun housesl Pool enclosures l Parksl Porches l Verandas l Sun decks cladding l Chemical & pharmaceutical plants l Livestock structures l Walkway coverings l DIY (Do-It-Yourself) jobs.
The details information of double layer metal roof panel roll forming machine
| Shaft material | 45# steel with tempering, shaft diameter 70mm |
| Roller material | 45# steel with chromeing plating |
| Roller station | 11+12 stands or as your need |
| Forming speed | 15-20m/min |
| Main motor power | 4+4kw |
| Main frame | 350mm H steel |
| Chromium plated roller surface | 0.05mm |
| Voltage | 380v 50hz 3-phase |
