Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment

Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment
Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment

صورة كبيرة :  Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment

تفاصيل المنتج:
مكان المنشأ: Botou Hebei China
اسم العلامة التجارية: HC
إصدار الشهادات: ISO
رقم الموديل: HC760
شروط الدفع والشحن:
الحد الأدنى لكمية: 1set
الأسعار: 5000-19000USD
تفاصيل التغليف: Main machine is nude,the computer control box is packed by carton box
وقت التسليم: 30days
شروط الدفع: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
القدرة على العرض: 20 sets/month

Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment

وصف
تسليط الضوء:

steel roll forming machine,door frame roll forming machine

,

door frame roll forming machine

Garage Door Steel Cold Roll Forming Machine , Sheet Metal Forming Equipment

Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 1000mm

3. Rollers: 18rows

4. Dimensions: 8.6*1.45*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Rolling Shutter Door Roll Forming Machine Main parameter

No.

   Main parameter of Rolling Shutter Door Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1000mm

3

Rollers

18 rows

4

Dimensions

8600*1450*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.6mm

7

Productivity

20m/min

8

Diameter of the roller

Φ66 mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting





Application



This type of sheet can be widely used as the door of garage, storage and supermarket.





Competitive Advantage



1. ISO/CE certification

2. 20sets/ month

3. high-speed production

4. easy operate, easy maintain

5.One year free warranty
